FS-43
2″ Turnkey Bulk Water Dispensing Station with Backflow Preventer
Best for: cold-climate potable water sites that need a complete 2″ station.
The FS-43 combines the full FS-20 platform with an enclosed, temperature-controlled meter, valve, and backflow preventer, so potable service continues safely through winter.
The FS-43 combines the full FS-20 platform with an enclosed, temperature-controlled meter, valve, and backflow preventer, so potable service continues safely through winter.
A potable fill station in a cold climate must protect its meter and prevent backflow. The FS-43 is a turnkey 2″ bulk water dispensing station built for harsher climates. It includes a temperature-controlled meter, valve, and backflow preventer, and supports multiple outlets.
Standard Features
- Keypad or touch-screen access display
- Secure PIN access control
- Lockable, painted galvanized steel enclosure
- Temperature-controlled meter, valve, and backflow preventer
- Integrated management and payment portal
- Configurable pricing by user type or volume
- Standalone, turnkey station
- Enclosed meter and valve for 3/4" (hosebib)–2″ piping
Optional Features
- Point of sale payment methods: Credit card reader, bill acceptor, coin acceptor
- Additional access methods: RFID card, key fobs, and others
- Multiple-outlet configuration
- Heavy duty kiosk-style printer, illuminated chute
- Cloud hosted software package
- Custom logic and programming
- Solar / off-grid power package
FS-43 Model use cases
Common Applications:
- Cold-climate municipalities dispensing potable water year-round
- Sites that require code-compliant backflow prevention
- Water haulers and agricultural users at 2″ fill rates
- Rural and unserviced-area potable water access points
- Sites looking for the convenience of a fully configured station rather than a retrofit to existing equipment
.webp)
FS-43 Specifications
Specifications:
Type:
Turnkey standalone station with backflow preventer
Dimensions:
48″ L × 36″ W × 75″ H
Enclosure:
Lockable, painted galvanized steel
Hauler Access:
Multiple access methods including keypad entry, swipe cards, key fobs, credit/debit card, and others as required.
Piping:
Enclosed meter and valve, 3/4"-2"; Muliple outlet option
Flow Rate:
100gpm-200gpm
Power:
240/120 VAC, 20 AMP
Interface:
Control and monitor valves and meters, gates, sensors, and more
Temperature:
Operating temperature range -40°F to 122°F (-40°C to 50°C)
Software:
Station interfaces with Portalogic management software for record keeping, billing, monitoring, and reporting
Certifications:
UL and CSA Listed, AIS and BABA Compliant
